e greatest importance attached toseveral other instruments, which will be referred to in this work, wenow make an effort to give the learner a clear comprehension of it. Let AB represent aportion of an arc and EDthe vernier whicV is con-ceived to be attached toan index bar and madeto revolve with… … 86 SURVEYING. scale to see what division of it makes a right line with some divisionon the limb, suppose the division 8 on the vernier coincided with adivision on the limb then the index would mark 10° 8. To understand the philosophy of this : Let x represent the valueof a division on the vernier…
