Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1093

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 1093
to the diagram of any winding will show that 1058 Steam Engineering the brush while collecting current is at the same time sliortcircuiting one of the coils. In order that an excessive current may not be generatedin this short circuited coil it must be out in the interpolarspace at the time the… … Fig. 450 and deliver it to the outside wires in the case of a d}raamo,and for the opposite in the case of a motor. There are many different designs and constructions ofbrushes and brush-holders, and these designs are broughtabout by the various ideas of different builders in their at-tempt to…

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
