Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 243
l 1: 1 1 1 - -- 1 - L Rankin Bridge. 226 BRIDGE CONSTRUCTION in 15 to 20-ft. lengths, shop-spliced with pairs of 14 X |-in. coverplates with four vertical rows of rivets. Each flange angle ismade in three pieces with their joints staggered on oppositesides of the web but opposite each other, top… … l-dOx^Co\/. PI. Second Flange SplicePine Creek Bridge, N. Y. C. & H. R. R. R. of the center each angle is separately spliced with a pair of shortangles as here shown, all the splice angles being made from8 X 8 X l-m. bars with each flange cut down to 6} in. wide, andthe back rounded to fit the…
Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
