Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 267
X-brace angles. The^ chords of these girdersextend from out to outof the column bent, andare riveted across thecolumn flanges on eachside of the column. Theupper strut is 4 ft. deep,and has four 6-in. chan-nels ; the next one is 6 ft. deep, and has 8-in.channels; the next is 7 ft. deep, and has… … 1 2 like a Section A-A Cfirder removed- Girder Bearing and Column Connections. a horizontal strut with 1-shaped cross-section, which is made of twopairs of angles latticed. The two horizontal panels thus formedare X-braced by single i i-in. rods pin-connected to the ends ofthe longitudinal struts,…
Bridges
