Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 341
circle to be tangent to both web stiffeners of the samepanel. This arrangement gives the effect of an arch span withslender spandrel arches carrying the roadway platform. Theflanges are made with pairs of 8 X 8-in. angles and i8-in. coverplates in three lengths, spliced with cover plates and… … Half Transverse Sec+ion.Roadway and Sway Bracing. wooden nailing pieces. At the ends of the bridge the girdersare sway-braced by transverse bottom struts and diagonal anglesin the planes of the fioorbeams. Riverside Drive Viaduct, about 1750 ft. x 80 ft. The Riverside Drive viaduct, New York, is 80…
Bridges
