Hole for l^ Anchor Bolt <rBolf^ … 52-F00+ Oirder Span.Girder Details and Connections.—^A^oodsville Bridge. beams, which are web-connected to them. The shore end floor-beams are set lower than the intermediate floorbeams, so as tosupport the main stringers directly on their top flanges. Theintermediate floorbeams are web-connected…
