ontribute to give firmness to the system,—to prevent thetubes fi-om losing then- perpendicularity parallel to the frontwall. The two cheeks of plate-iron e prolonged above the topedge of the tube, receive the clips k of the giider, whoseanterior extremity L rests on the end i of the bracket. At N… … Fio. S. —ExniiiiIe of Irou-fraiiK-d Street House.—Details of Construction. gives the skewback of the brick arches indicated at G m figure 7.An upright of the iron-framed partition is drawn at o. We 324 LECTURES ON ARCHITECTURE. have mentioned flues for fireplaces that will require to be carriedup…
