Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 75
-in. spans with girders 29 ft.apart on centers and skewed 36 ft. 5^ in. The girders are 90in. deep with web plates | in. deep, and up to 21^ ft. long,and are spliced with four vertical rows of shop rivets throughpairs of cover plates. The maximum flange section is madewith two 8 X 8 X f-in. angles,…
Bridges
