Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 83
Aif 1^® 4^- @ ©© … Fig. 160—Gusset Stays. in a diagonal direction from the flat end of theboiler to the cylindrical shell. One end of thisplate is placed between and riveted to two angleirons which are riveted to the shell of the boiler. MACHINE DRAWING 81 A similar arrangement connects tlie other end ofthe stay…Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
