Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 75
°jll RAILROAD PLATE GIRDER SPANS 59 The web is divided into panels about 5 ft. long by pairs of5 X 3i X f-i^- angles at splices and intermediate points andfillers. The upper corners of the shore ends of the girders arerounded to a radius of 28 in., and the top chord flange anglesare cut off tangent…
Bridges
