Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 105
r\ STEAM CHAMBER EXHAUST CHAMBER FIG. 98.—VERTICAL SECTION C-D. … and supplies its steam from the inside; its motion is just opposite to thepiston movement, and its eccentric follows the crank instead of leadingit, as shown in the skeleton diagram of Fig. 94. The balance pistons Bare packed in their bores by spring rings, and have a scraped joint on theback of…
Steam-engines
