Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 143

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 143 — the new-style regulator, Fig. 136, is somewhat different and isoperated in the following manner: After all the connections have beenmade, raise the balls until the clearance S, between the center weight andthe collar, is ^ of an inch. Hold in that position and push the levers of2 and 3 in far… … FIG. 135. — SECTIONAL VIEW OF VALVES AND STEAM PASSAGES. under, the positions of the collar D, Fig. 131, and the gear are exchanged.The lay shaft revolves in the same direction in all cases. The changingof the position of the gear changes the direction of rotation of the engineshaft. The question…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
