Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 150
FIG. 143. — ADJUSTABLE LOW-PRESSURE ECCENTRIC. FIG. 145.— THE INERTIAGOVERNOR. … FIG. 144. — LOW-PRESSURE VALVE SIDESHOWING LEAD ON BOTTOM END. FIG. 146. —THE GOVERNOR INPOSITION. 140 VALVE SETTING The high-pressure crank should be placed on the top center. The loweredge of the upper port is 5f|- ins, below the top surface T of the valvechamber. Since the thickness of the…
Steam-engines
