Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 831
FIG. 5 Hornsby-Akroyd vertical engine. 810/ Steam Engineering … 13 Oil spraying- nozzle. 14 Control lever. 15 Hand hole cover. 16 Crankpin brasses. 17 Flywheel. 18 Governor weight. 19 Cam. FIG. 6 Names of Parts. 20 Stud carryino- governor weight. 21 Crankcase end plate. 22 Wrist nin bushing. 23 Exhaust pipe flange. 24 Speed control segment. 25 Bracket carrying…Steam engineering · Electrical engineering · Steam turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
