he arm c which actiiates the rock shaft d. To this shaft are attachedthe arms e e, which draw the splined spindle through the hollow rock shaft. Both the steam and exhaust valves work vertically and are actuatedby valve stems extending downward through stuffing boxes in the bottomsof the chests.… … THE WRIGHT STEAM ENGINE 161 The two shafts which carry the valve cranks are hollow and stationary,each having one steam and one exhaust crank on their respective ends.The main steam valve stems are fastened into the yokes with set screws,and on their lower ends the yokes are provided with dash…
