Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 173

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 173 — FIG. 165. 162 VALVE SETTING one of the shafts. The sj)lined spindles / / pass through the hollow rockshafts and valve cranks as shown^ and on one end is a nut g which canbe adjusted to lengthen or shorten the spindles. At h is shown the keywhich is set diagonally across the end of the spindle and… … /■ -. ^ 3 v//y///////////^^^^^^^^z^ V,

Steam-engines
