Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 50
FIG. 35. ample being set exactly opposite at N and the main eccentric at M, themain valve having no lead. It will be seen that the valves moving in thedirection denoted by their arrows, while the crank starts in the directionshown by its arrow, the admission of steam will occur through the portsK…
Steam-engines
