Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 55

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 55 — FIG. 46. center, the main valve having no lead, and the port a being closed. InFig. 47 are shown the positions at the point of cut-off, the crank havingmoved but 22 deffrees.

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
