Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 83

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 83 — FIG. 70. It will be seen by this that the valve moves four times between thepoints of closure and opening, which is a distinctive feature of this valve. 72 VALVE SETTING Conditions to be Avoided There are some general conditions which if they existed on this valvegear would cause trouble, and it is… … FIG. 71. eccentric rod is too long, the valve-stem latch and pusher may not engage,or if they do, the action may be too early. If the rod is too short, it willcause late action. If the outlet eccentric rod is too long it will cause the valve to open tooquickly, and running back too far will…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
