Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 87
le the valves are out of sight, a strictadherence to these rules of adjustment must be followed, care being takento be accurate, but Figs. 65, 66, 67, 68, 69, 70, and 71 will help to aclear understanding of what is done in this adjustment and subsequentoperation. VII THE BROW^T ENGINE The engine is… … FIG. 76. side of the cylinder and the exhaust at the bottom, the latter affording an ideal water drain, as shown in Fig. 76, which is a section through the valves and cylinder. The operation of the steam valves can best be 76 THE BROWN ENGINE 77 seen by referring to Fig, 77, which shows the…
