Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 89

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 89 — osingand provides a long dwell betweenthese points. The governor now providedwith these engines is of the typeshown in Figs. 79 and 80, the firstshowing the construction of thegovernor and the second its rela-tion to the trip shaft and otherparts of the engine. The centrifugal action of thetwo… … FIG. 78.

Steam-engines
