Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 238

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 238
their opposite focii,to which the hnk A, P, B,is attached. P, the pencil,which on moving from thecenter of the link, will pro-duce a great variety of curves. 609. CIRCULAR FROMRECIPROCATING MO-TION. A lever L, moved byany reciprocating power, op-erates the pawls on the meshedgear A, B, for a… … 236 GEARING AND GEAR MOTION, ETC.

Mechanical movements
