Fior. 91. Lay Forward ofPerpendicular. 147 134 WEAVING. The Lay. The following parts comprise the lay: Fig. 92,AA, lay sole, a long piece of wood varying in size, according to U =^=B … the width and make of loom; it is most commonly made fromwell seasoned ash. BB, two lay swords which support the sole; 148 WEAVING. 135- the swords are connected at the foot to the rocker shaft, the crankarms are also connected to a lug or bracket fixed at the back ofthe swords and lay sole. CC,…
