and slow motion. The gears are timedto impart their greatest speed during the change from one box toanother, which regulates the color of filling to enter the cloth.While it is not only advisable but necessary to have the boxeschanged in time, it is not always desirable to have too rapid action,… … § cq O bo 1, is fixed on the picking cam shaft and geared mto 2, each having27 teeth. Compounded with 2 is a 22-tooth gear and a segmentgear 3, which has 15 teeth. The 22-tooth gear is the firstof a train of four gears of the same number of teeth, which transmit 176 WEAVING 163 motion to the second…
