Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 97

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 97
cloth, 28 inches in the reed, 40^ reed;plain stripe to have, 60 ends in A of aninch ; satin stripe to have 50 ends in iinch: 5-harness satin weave. It is bestto have a striped cloth finished with bothedges alike ; that is, if the stripe near theselvedge on one side is plain, the stripenear the… … Fig. 45. Sectional view ofHarnesses. satin. The full patternthen be repeated 27 times, and there would be | of an inch ofplain left. This would make both edges equal. The plain shadeswould be ordered as follows: Two shades, knit 15 eyes on |- of aninch, drop 1 of an inch; then commence with full…
