The Whitin Machine Works, Whitinsville, Mass. builders of cotton machinery : cards, railway heads, drawing frames, spinning frames, spoolers, wet and dry twisters, reels, long chain quilling machines, looms, etc., etc (1896)

Whitin Machine Works (Whitinsville, Mass.) · East Douglas, Mass. : Batcheller · leaf 109

An illustration from The Whitin Machine Works, Whitinsville, Mass. builders of cotton machinery : cards, railway heads, drawing frames, spinning frames, spoolers, wet and dry twisters, reels, long chain quilling machines, looms, etc., etc, 1896, leaf 109
and 3 in. Side shaft tappetball shuttle motion. Beam heads 12, 13, 14, 15, 16 and 16J in.diameter. Geared let-off motion. Shuttle boxes 18 and 20 in. long.Made to weave plain 2 shade work, also 3, 4 and 5 shade twill.Arrangement of change pick motion same as in new Heavy PatternLoom. Pulleys:—10,… … It will be seen from the foregoing cut that the general con-struction of this Loom is the same as that of our regular HeavyPattern with Ponemah Side. The chief departure consists in placingthe harness cams and treadles on the outside of the Loom; thegreat advantage resulting therefrom being in the…

Whitin Machine Works (Whitinsville, Mass.) · Cotton machinery · Textile machinery

Internet Archive · Duke University Libraries · Public Domain Mark 1.0. Free to use for anything.
