The Whitin Machine Works, Whitinsville, Mass. builders of cotton machinery : cards, railway heads, drawing frames, spinning frames, spoolers, wet and dry twisters, reels, long chain quilling machines, looms, etc., etc (1896)

Whitin Machine Works (Whitinsville, Mass.) · East Douglas, Mass. : Batcheller · leaf 86

An illustration from The Whitin Machine Works, Whitinsville, Mass. builders of cotton machinery : cards, railway heads, drawing frames, spinning frames, spoolers, wet and dry twisters, reels, long chain quilling machines, looms, etc., etc, 1896, leaf 86
he same size. Theymay also be made forfilling wind. In ourtwisting frame, as nowmade, the spindle-rail isdropped so low that thebobbin having both headsthe same size may beused, and is the stylewhich we recommend.The spindle is made inthree sizes, which westyle the Wet Twister,Heavy, and the… … 8o THE WHITIN MACHINE WORKS. Dry Twister Change Twist Gear Tables. Rolls l| in. Diameter. Cylinder 7 in. dia. Whirl l^in. dia. Ratio of Cylinder to Whirl, 1 to 4.80. Cyl. 22 T. Stud 88 T. Cyl. 36 T. Stud 74 T. Cyl. 55 T. Stud 55 T. Roll 108 T. Roll 108 T. Roll 108 T. Stud. Twist. Stud. Twist. Stud.…

Whitin Machine Works (Whitinsville, Mass.) · Cotton machinery · Textile machinery

Internet Archive · Duke University Libraries · Public Domain Mark 1.0. Free to use for anything.
