Fig. 17. 90 THE WINDMILL AS A PRIME MOVER. on turn-table; ib, the front cap on turn-table; i^, frontbox on turn-table; id, rear box on turn-table; le^ clamp … bolt; 2, bed plate; 2^, anti-friction rolls and carriage; 3,forked lever; 3^, weight on forked lever; 4, main shaft; AMERICAN WINDMILLS. 91 5, spider; 5^, elbow; 5^, elbow collar; 6, back plate; 6a,shoes on back plate ; 6b, front-plate and slide-head rods ;6c, link connecting back plate to elbow;…
