Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 142

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 142 — o prepare a chuck large enough in diameter;turn its face perfectly flat, and glue paper all over it. The stock required, as illustrated by Fig. 65, mustbe large enough to contain the size of pattern it is pro-posed to build, indicated by the circle on the figure. This PIPE FITTINGS 127 should be… … Fig. 65. lathe that the joint shall be exactly on the center of thelathe. The best way to do this has already been explainedin connection with core box ends, page 75. They arenow to be turned to the shape indicated by Figs. 66. The

Patternmaking
