Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 189

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 189 — Fig. 10. the beam slides is called the head. The graduations onthe beam are not to be depended on for accurate meas-urements. The mortise ^au^C has two spurs; one of themis moveable on the beam and is fastened to a brass slide … Fig. 11. that is moved back and forth by a thumb screw at theend of the beam. This is shown at Pig. 11. APPENDIX 175 Fig. 12 CHISELS AND CHISEL-LIKE TOOLSThere are two general formsof chisels used by wood-work-ers, viz., the tanged or shank,and the socket. These termsrefer to the style of handleand…

Patternmaking

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
