e face-sur-face or the back-sur-face. For this piecethe chamfer is on the face surface (Fig. 82.) Usually the lines are the same dis-tance from the edges. In this drawing (Fig. 75 ) they are % inchfrom the corners, therefore set the gauge at % inch and drawthe lines without changing the gauge, for… … Fig. 83—Chamfering End 76 WOODWORK FOR THE GRADES fers equal, and if we gauged all from the face-surfaces theywould not be alike unless the piece were the same width at each end. Use a pencil inmarking for chamfers and drawlines across ends as well asedges (Fig. 82). In working the chamfer,place…
