Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 119
Fig. 154—Third Section Planed cally. In finishing the surface the plane should be set veryfine and the shavings taken so carefully that there will be no 116 WOODWORK FOR THE GRADES visable marks where the plane begins to cut or where the shavingruns out. The shelf may be dressed on both surfaces in… … Fig. 155—Sawing Ends be held on the bench by using two bench-hooks as shown inFig. 155. Finish the ends the same as the large piece of thebench-hook (Lesson 16). The corners of this shelf may becut off where indicated by the dotted line; being done as inmaking Fig. 143. WOODWORK FOR THE GRADES 17…
Woodwork
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
