se the plane so much less that it will remain sharp much longer. If, in using the plane, as it is drawn back the cutting edge rubs upon the surface of the piece being planed, the edge will be dulled more 1 than while cutting on the forward stroke. Because of this you should either lift, tilt or… … 40 WOODWORK FOR THE GRADES of the plane instead of on the cutting edge of the bit. For mostwork this is the best way to hold it on the return stroke. Sometimes the piece is too narrow to permit of lifting it inthis manner. It may then be turned to an angle as shown inFig. 39. This is the usual way…
