he rule, use the markings away from the end, if thiscan be done. In Fig. 54 the scale is placed so that an inch line is at the edgeby the face-mark. It is notincorrect tohold it so thatthe inch line isat the oppositeedge. Alwayshold the rule inthis manner formeasuring andyou will soon doas… … Fig. 54 - Measuring Width with Rule WOODWORK FOR THE GRADES 51 the line entirely away, the piece is one-half the width of the linetoo narrow. This is because the spur bruises the wood ateach side of the point and makes a line of some width. Forthis reason, in setting the gauge for planing to width…
