todo the work of a (1) header, center header; (2) rabbetand filletster; (3) dado; (4) plow; (5) matching plane;(6) slitting plane; (7) sash plane; (8) niolding plane.Varying sizes for eacli kind of cutter make possible an TOOLS AND PROCESSES. 47 unlimited variety. The plane is possessed of a… … Fig. 73. Universal Plane. of the cutter which slides on arms secured to the mainstock. This bottom can be raised or lowered so thatcutters can be used having one edge higher or lower thanthe edge supported in the main stock, in addition to al-lowing the use of cutters of different widths. An extra…
