Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references (1921)

Fairham, William · Philadelphia and London, J. B. Lippincott company · leaf 194

An illustration from Woodwork joints; how they are set out, how made and where used; with four hundred and thirty illustrations and a complete index of eleven hundred references, 1921, leaf 194 — urse, be squarewith its edges before marking out in this manner. Fig. 403 shows a bevelled framing into which has been 182 The Mitred Joint mitred a narrow moulding M so as to show a correctmargin around the panel. Fig. 404 shows a similar framing, but with a wide mould-ing M mitred around it. To… … Fig, 405.—Door with Curved Mitres. bisected, and the finished joint will appear as shown. Oneof the simplest of mouldings with a large fiat face has beenchosen to illustrate this. The moulding could be all inone width, as shown, or it could be built into the framingin separate pieces, the wide flat…

Woodwork · Carpentry

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
