Woolen and worsted finishing; a practical manual of instruction in the methods and machinery used in finishing woolen and worsted goods in general, and the processes involved in the special treatment of all types of standard fabrics (1909)
American School of Correspondence, Timmermann, John F · Chicago, American School of Correspondence · leaf 138
t roll D draws the cloth from the scray Ubeneath the machine, pulling on the back of the goods so that thenap on the face is not displaced: from there it passes over thebrush rest F, where the raising brush E raises the nap so that itstands perpendicular to the face of the goods, in a fit condition… … 5 ^a: P^ WOOLEN AND WOKSTED FINISHING 115 to stand up straight. The brush G is a flock brush which cleansthe back of the cloth from threads and flocks before it goes overthe rest H, where the fly blade I revolving against the stationaryknife Y cuts off the nap from the face of the goods. The screw
Woolen and worsted manufacture · Textile finishing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
