ngbalanced by a spring on the other side of diaphram. Thespring is adjusted by small plug to desired pressure andlocked by nut to prevent variation. The valve can be assembled any way with reference toinlet and outlet lines. When excessive pressure isreached, the spring releases and allows air to… … Showing the piston and connecting rod construction peculiar to model AAlso the double intake on the water pump :^ MODEL A—SPECIAL POINTS IN DESIGN Model A Was the Original Wright, AlmostIdentical With French Hispano-Suiza Motor T HE most conspicuous differences between the de-sign of Model A and…
