The young mechanic; containing directions for the use of all kinds of tools, and for the construction of steam engines and mechanical models, including the art of turning in wood and metal (1902)
[Lukin, James] [from old catalog] · New York, London, G. P. Putnam's sons · leaf 116
eed of very generalapplication in every household, and it is well worth whileeven for the young mechanic to learn how it is accom-plished. It is absolutely necessary, however, that he PANELLING. lOl fihould be possessed either of a plough or match-planes forrouting out the grooves in which the… … Fig, 40. are cut as usual. The inside edges of C, B, D, G are thengrooved with the plough, and both edges of the otherpieces. The panels are carefully squared up, and thenbevelled off at the edges so as to fit the grooves. To putBuch a door together, A, D, G, E, and F would be first I02 THE YOUNG…
