Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 209
PLATE H. YOKE, STUFFING BOXES, BRACKET, ETC. Having worked up the layouts of Plates E and F, the studenthas enough information to proceed with Plate H. This, like PlateB, is without dimensions, the students work being to make thedrawing and fill in the necessary shop data. Specifications. The… … MACHINE DRAWING 197 same level as that beneath the water cylinder. The tapped holes inthe top surface receive bolts from the cylinder foot. These boltsare often used only for shipping purposes, the cylinder foot whenthe pump is set up being allowed to slide freely on the cricket, thuspermitting…
Machinery
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
