= AC and FX = DE ;make FG = FX and GH= GA; join HKMP, GLMP, A C.Y., thp: hexagon. 51 I) C.V., E C.V. and C C.V. At K, L ereol perpendiculars tomeet vanishing lines in N and M ; join ^IR, MD, LE andLP : then RMDELPR will be hexagon required. For AK =AH and AL = AG = FX = 2, and DE = RP and ML = NK… … 52 DRAWING. Draw H.L., B,L., and find O C.V. and MP as before.Make SY and ST each = 1, and make TX and VA each = 1;make AF = 2, and draw it _i_ to AX; draw XP, TY, YZparallel to AF. Make RG = RL or TY, and GZ also = RL,and complete the oblong MH. Make Aa = AF, A6 = AG andAE = AH; join EMP, 6MP,…
