Fig. 44. 76 DRAWING. Example 2.—Draw a cylinder lying on G.P., 4 to right,having end perpendicular to P.P.. and toucliing it; cylinder 8 long and 3 in diameter. … Take A, 4 to right and E, 4 to left; make AB= H, anddescribe circle; join B C.V. and A C.V., also E MP, and fromC, draw CD parallel to AB, and describe smaller circle; thendraw common tangents, completing the cylinder (Fig. 45.) THE CYLINDER. 77 Example 3.—The figure shows how to draw a common…
