An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)
Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 424
with anave and side aisles, we may make Be in thediagonal B1) (fiff. 605.) equal to one twelfthof the iieiglit above the springing of the sideroofs, and efa twenty-fourth i)art of thnt heightbelow it, and draw througli the point / a lineparallel to AB, which will determine tlie thickness A/ sought;… … Second Example.1546. Fig. 605. is a section of St. Paolo fnori le mura, near Rome, as it was in 1816.
Architecture · Architects
Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
