An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)
Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 622
e found in the same manner. 1982. To find the joint mould itself. Draw the line III {fig. 654.) equal in length to thedevelopement of the intrados, and let He , , j fbe the developement of the arc ac ; drawcm perpendicular to HI. Draw any lineWX in the plan parallel to VD, inter-secting the lines…
Architecture · Architects
