An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 662

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 662
Chap 111. CARPENTRY. 641 … circle EqruV draw ts perpendicular to BD, cutting the circumference of the semicircle in s.Draw if parallel to B D. From the centre y, with the distance yp, describe the (juadrantpm. Draw mi parallel to AB, cutting the semicircle described upon AB in the point i.In the arc Bi take any number of…
