An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)
Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 832
directed from theeye to tlie diHferent parts of the object. A delineation so made, being pro])erly colouredand shadowed, will conxney a lively idea of the real object, and at the same time indicate itsposition and distance from the eye of the observer. 2406. Definitions. — 1. An original object or… … Fig. 829. Original lines are any lines that are the boundaries of original objects, or of planesin those objects. The lines AB, BC, CD are original lines, being partly theboundaries of the original object ABCDFIIK.The ground plane is that upon which the objects to be drawn are placed, ftnd is il2…
Architecture · Architects
Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
