Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)

M.H. Detrick Company. · M.H. Detrick Co. · leaf 44

An illustration from Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills, 1921, leaf 44 — ARCHES … H. R. T. Boiler and National Stoker. Note Detrick Rear Arch Detrich Special Circular Arch Construction with H. R. T. Boiler

Building materials · Masonry · Refractory masonry · Flat arch

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
