quarter circle, APC; draw tan-gents AB and CB, join AC; through the point B drawa straight line parallel to AC; with center B, withradius BA, describe the arcs AD and CE; at the pointE erect the perpendicular EF at right angles to DE toany desired height (in laying out a handrail this heightwill be… … i6 COMMON-SENSE HANDRAILING
