Common-sense stair building and handrailing (1903)
Fred T Hodgson · Frederick J. Drake and Co. · leaf 73
THIRD METHOD P To draw the development of these tangent lines,with A as center turn AB around, and with E ascenter turn EF around, erect perpendiculars fromB, A, D, E, F; then place the pitch-board with therisers to the perpendicular springing line at B, anddraw the under side of rail from where…
Wood stairs and railings · Woodwork · Architecture, Domestic · Designs and plans
Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
