8 lbs. 18 x!8 in. 75 lbs. Round Flues(Without Sockets) Inside Weight Inside Weight Measure per Foot Measure per Foot 6 in. 15 lbs. 20 in. 87% lbs. 7 in. ivy> lbs. 21 in. .... 8 in. 20 lbs. 22 in. 9 in. 25 lbs. 24 in. 125 lbs. 10 in. 27y2 lbs. 27 in. 12 in. 32% lbs. 30 in. 220 lbs. 15 in. 55 lbs.… … HOW TO READ PLANSCHAPTER XXVIII. 199 FIGURING BRICK FOR A HOUSE Figs. 168 to 173 show elevations and plans of a substantialmodern brick dwelling house of 7 rooms, with bath,, receptionhall, and basement. We shall now endeavor to show themethod of procedure to be followed in estimating the numberof…
